A302 Gr.A Normalized Steel Plates

A302 Gr.A normalized steel plate, under ASTM A302/A302M standard, is a kind of manganese-molybdenum alloy steel for welded boilers and pressure vessels. ASTM A302 Gr.A pressure vessel plates 2 inch [50mm] and under in thickness are normally supplied in the as-rolled condition. The plates may be ordered normalized, normalized and tempered, or stress relieved. ASTM A302 Gr.A plates over 2 inch [50mm] in thickness shall be normalized or normalized and tempered.

ASTM A302 Gr.A Plates Dimension

Thickness: 6.5-150mm
Width: 1220-4200mm
Length: 5000-18000mm
Note: the maximum thickness of A302 Gr.A plates is limited only by the capacity of the chemical composition to meet the specified mechanical properties requirements. The minimum thickness is limited to 0.25inch [6.5mm].

 Technical Requirements & Additional Services

High tension test
Low temperature impacting test
Normalised for thick plates over 40mm
Simulated post-welded heat treatment (PWHT)
Rolling under standard NACE MR-0175 (HIC+SSCC)
Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
Shot blasting and Painting, Cutting and welding as per end user’s demands

A302 Gr.A Normalized Steel Plates Application

ASTM A302 Gr.A normalized steel plates are manganese-molybdeum-nickel alloy steel plates, which are widely used in petroleum, chemical industry, power station, boiler, etc, to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station and so on.
